RALLY Aircraft

State of the art design!



The Storm Rally is the latest in state of the art Special Light Sport Aircraft design. The Rally is a result of many years of extensive research and development; carbon fiber and Kevlar are utilized in the construction of the Rally to create a lightweight and extremely strong airplane. Its composite structure is not subject to rot, rust or corrosion. This design increases performance and helps to reduce maintenance and repair costs. This SLSA aircraft has the largest overall cabin in its category/ class/set available on the market today. The well designed and placed windows provide over 300 degrees of visibility for the pilot and passenger. Its unique gull type door design allows for easy entry and exit by pilots or passengers over 6í2 tall! These doors can be opened in flight at speeds of 60 knots or less for incredible photo and/or video taking opportunities.









The aircraft is forgiving, quick, responsive and precise to the pilotís touch. The Rally SLSA has exceptional natural Short Take off and Landing (STOL) performance characteristics do to its extraordinary aerodynamic design and can be used for Visual Flight Rule (VFR) night flight and/or (IFR) Instrument Flight Rule flight operations (provided the individual aircraft is equipped with the required FAA-Federal Aviation Administration certified equipment for these operations).



This aircraft offers exceptional high-wing performance, pleasure, economy and safety to the sport pilot ... but also provides all other certificated airmen new opportunities for affordable personal aircraft ownership and air travel. Get above the traffic jams and highway stress with an aircraft that will get you there and back for

less than half the fuel and time that an automobile can!







        RALLY SPECIFICATION



Exterior Dimensions

Span .......................................................................    30 ft 1 in

Length......................................................................    23.2 ft

Height......................................................................      7 ft

Wing Area................................................................  124.96 sq ft

Interior Dimensions

Cabin Height (top of seats to roof)................................    40 in

Cabin Width (door to door, at the handle) .....................    43.7 in

Cabin Length (instrument panel to rear bulkhead) .........    70 in

Baggage Space.........................................................    16 cubic ft

Powerplant/Systems

Model.......................................................................     Rotax 912 UL S2

Power/rpm................................................................     100 hp / 5800 rpm

Propeller

Type .......................................................................      3 blades ground adjustable

Diameter .................................................................      70 inches



  PERFORMANCES CHART



Speed

Maximum at sea level.............................................    120 knots

Cruise (75% power at 2000 ft, ISA conditions) ..........    107 knots

34 Gal Usable Fuel   ..............................................    Time 7.2 hours

Cruise

75% at 2000 ft (ISA conditions)................................   Range 800 Nm

Rate of climb at sea level.........................................   800 ftm

Service ceiling......................................................... 12000 ft

Takeoff Performance - (ISA Conditions - Sea Level)

Ground roll ............................................................    360 ft

Total Distance over 50 ft obstacle.............................    600 ft

Landing Performance - (ISA Conditions - Sea Level)

Ground roll ............................................................    450 ft

Total Distance over 50 ft obstacle.............................   1000ft

Stall Speed

Flaps up, power off..................................................................      44 knots

Flaps down, power off..............................................................      35 knots

Maximum Weight

Light Sport Aircraft rules ...........................................................  1320 lbs

Standard Empy Weight

Light Sport Aircraft.....................................................................   760 lbs

 Maximum Useful Load

Light Sport Aircraft.....................................................................   560 lbs

Wing Loading

Light Sport Aircraft...................................................................  10.34 lbs/sq ft

Power Loading.......................................................................   13.2 lbs/hp

Total Fuel Capacity

Standard Wing Tanks..............................................................   35 gal/34 usable

Oil Capacity ...........................................................................   0.8 gal
